Finn Mast Deck Bearing Collar and Slide

We manufacture Finn mast deck collar bearings and deck slide inserts.

Finn mast deck collar

Available as either the bearing and spacer set alone ( to a specified width -- standard width 130mm, Devoti width 140mm) or as a complete unit ready to drop into a rectangular hole cut into the fore deck.

Finn mast deck collar

Mast Deck Collar Set

Size - 130mm square, 104mm diameter hole, 20mm deep.

Centre hole machined at 5 degree angle to allow mast rake without excessive binding.

Set includes 2 retaining brackets (including 5mm C/S mounting bolts)

Plus 6 10mm and 2 5mm lightweight spacers.

Fibreglass or carbon fibre deck insert available. Scroll down to see complete unit.

Part Number V-Tech_303 -- Mast Deck Bearing Collar ---- NZ$200.00 (excluding GST)

Finn mast deck collar

Carbon Deck Slide Insert for Finn Mast Deck Collar Set

Installation instruction for V-Tech_343 -- Finn Mast Deck Slide Insert (right click and "save as" to download).


Part Number V-Tech_343 -- Finn Deck Insert Carbon ----- NZ$150.00 (excluding GST)



Finn mast deck collar

Also available in fibreglass for those who are going to repaint the foredeck.   Save NZ$70 on the price of a carbon insert.


Finn mast deck collar

Standard Devoti type Finn mast deck collar

Size 140mm square, 104mm diameter hole, 20mm deep.

Centre hole machined at 5 degree angle to allow mast rake without excessive binding.

Price NZ$120.00 (excluding GST)


Finn mast deck collar

Custom Mast Deck Collar

Any size and configuration to suit specific design needs.



Price NZ$150.00 (excluding GST)


Finn mast deck collar

Customised with dual insert to enable either an older mast with 100mm dia mast bearing or a newer mast with 103mm diameter mast bearing to be used on a single boat.

Centre holes machined at 5 degree angle to allow mast rake without excessive binding.

Price NZ$150.00 (excluding GST)


Finn Mast Deck Collars and Slides can be made to custom diameters and lengths or alternative material and configurations, price on application.

Contact us directly using the details at the top.
